Product Name

Handheld Inkjet Printer

Feature

Easy to Oprate, No App , Derectly Printing, Stable System

Material

ABS

Size

L 12.5 * T 9.5 * H 23cm (3.6 * 2.7 *6.3 inch)

Display Size

4.3 Inch Touchable Screen

Weight

0.47 kg

Voltage

7.4V

Gross Power

2W

Printing Line

1 – 6, Adjustable

Printing Height

1~12.7mm, Adjustable

Printing Resolution

300DPI / 400DPI / 600DPI Adjustable

External Interdace

USB, Charging port, Photoelectric Interface

Ink volume

42ml(usually can at least print 100,000 characters)

Ink Color

Black, Blue,Green, Red, Yellow, White

Ink Type

Fast Dry Solvent Ink

Battery

2000 mAh

Language

Simplified/Traditional Chinese, English, Japanese, Korean, Spanish, Portuguese,French, Italian,Turkish, Arabic,Russian,Vietnamese, German, Dutch, Thai, Hindi, Persian, etc.

Printing Content

Text, Date, Image, QR codes, Barcodes, Var Barcode,Time, Form Files, Tabel, Counter, Logo, Paragraph.

Application

Paper, Plastic, Carton, Wood, Glass, Acrylic, Metal, Stainless steel, Aluminum foil, Woven bag, Foam, Leather, Cloth, ABS, Rubber, Non-woven fabric, Bamboo, Ceramics, Stone, Pipe, etc.

Working environment

Temperature:0 – 45 degree; Humidity: 40% – 60%

Brand

Imprint

Product name

Handheld smart inkjet printer

Printing Direction

Adjusted within 360 degree,can meet all kinds of production needs

Character Type

High-definition printing character ,such as dot matrix font,simplied ,Chinese ,English and Multi Language

Function

Handheld print and online printing （need sensor extra）

Print Pictures

Pictures(BMP single bitmap format can be uploaded through USD disk

Print Height

1mm-25.4mm ( Different Price )

Print Code

Bar code,QR code

Print Distance

1-10mm Mechanical Adjustment(the best distance between the nozzle and printed object is 2-5mm)

Print Serial Number

0-9

Automatic Print

Date,Time,Batch number ,serial number and etc

Storage

External USB save the information transfer in a free way

Message Length

2000characters for each message,no limitation on length

Print Speed

70m/min

Ink Type

Quick-dry environment ink,water-based ink and oily ink

Ink Color

Black,white,red blue,yellow,green invisble

Ink Volume

45ml(Usually can print 800,000 characters)

Print Material

Board,Carton,Stone,Cable,Metal ,Material,Plastic Product,Fiber Board,Light Steel Keel,Aluminum Foil

Brand

Imprint

Item

Handjet Ink Printer

Shape features

stainless steel casing/black aluminum shell and color touch screen

Dimension

135*128*200mm

Net weight

1.18kg

Printing direction

adjusted within 360 degree, meet all kinds of produce needs

Print fonts

Built-in full word stock, pinyin input method, touch online editing, no need to connect the computer and easy to operate

Character type

high-definition printing character, dot matrix font, built-in Chinese and English

Printing graphics

all kinds of logo, graphics can upload through USB disk

Printing accuracy

600DPI

Print line

1-8 lines (adjustable)

Print height

1mm-50.8mm

Pipe line serial number

1-9 lines

Automatic print

date, time, batch number shift and serial number etc

Storage

the system can store more than 1000 mass (external usb make the saved information transfer in a free way)

Message length

2000characters for each message, no limitation on length

Print speed

80m/min

Ink type

Quick-dry environmental ink, water-based ink and oily ink

Ink color

black, red, blue, yellow, green

Ink Volume

65ml(can print 80,000,000 characters)

External interface

USB,DB9,DB15, Photoelectric interface, can directly inserted into the U disk to upload information

Voltage

DC12.6 lithium battery,print continuously more than 10 hours and 20 hours standby

Control panel

4.3 inch touch-screen

Voltage

12.6-16.8 V

Power consumption

the average power consumption is lower than 5W

Working environment

0- 38 degree; Humidity: 10% – 80%

printing material

wood plate, cartons, stone material, the fiber board, light steel keel, tubing, metal, plastic, aluminum foil, etc.

Production Name

Handheld Inkjet Printer

Printing Height

<=100mm

Nozzle Type

TIJ handheld printer

Printing Distance

2~5mm

Printing Accuracy

600DPI

Printing Content

Text,time,count,barcode/QR code,LOGO etc

Printing material

Cardboard,plastic,Metal,cables,pipes,glass,electronic components,etc

Ink cartridge type

Solvent-based ink/42ml,water-based ink/42ml

Ink cartridge color

Black,red,blue,green,yellow,white

Screen size

7 inch intelligent touch screen

External interface

Photoelectric sensor interface, USB interface

Machine size

260*170*185mm

Battery Power

2600mAh,16.8V

Support Languages

Chiness,English,Italian,Russian,French,Spanish,Portu-guese,Arabic,German,Japanese,Korean,Thai,etc.

Power adapter

100~240VAC INPUT,16.8V/2A DC OUTPUT

Working environment

Temperature 0-45°C,Humidity 30-70%RH
